QUALITY CONTROL




The key factor to assessment is Quality Documentation & adherence to specifications imposed by various Standards / customer requirements. Which Transmits attached importance to field Performance of Manufactured product. So rigorous testing for certifications are issued in following manner.



  Certification format for Timer Board & Electronic Products :








  FORMAT FOR ROTARY AIR LOCKS

  Note: Following Certificates will be furnished with Each Rotary Valve.


SrNo Test Description Test Limit/Value Remarks
  MATERIAL TESTS
1 *O.H.N.S. material & Heat treatment Certificate .
2 *O.H.N.S. Tips Hard chrome plating.
3 Low Alloy Cast Iron Certificate
4 Gun Metal Bushing
5 High Tensile Hardware (Nut & Bolts) Certificate
  METALLURGICAL TESTS
6 Gas Nitriding Certificate
7 *EN 19 Shaft Hardening Certificate
8 Graphite Ring Certificate (type test) (For Glanding Applications)
9 *O.H.N.S. Blades hardness
  MECHANICAL TESTS
10 Dimensions as per drawings
11 Side flanges/Bearing/Rotor assembly
12 Gear Motor Mounting/Chain Sprocket Assembly
  ASSEMBLY STATIC & RUN TEST
13 Bearing NTN (JAPAN) (type test)
14 Noise Certificate (db Level) [For Running Assembly]
15 Radial & Axial Gap & Clearance Certificate
16 Purge air sealing & Graphite glanding Test
17 Powder coating Visual
18 Vent venturi operation
  ELECTRICAL TESTS
19 Electrical motor current
